Jiangsu BOE Environmental Protection Technology Co., Ltd.

and Xi'an Jiaotong University have jointly developed a complete set of in It has successively launched a low-temperature sludge belt dryer, a low-temperature sludge waste heat dryer, and a low-temperature sludge Box-type dryers and other models have advanced technology and remarkable treatment effects.

Two invention patents have been declared. Sludge heat pump drying airflow optimization system Air outlet drainage sludge drying system based on heat pump technology. Low temperature drying-the best solution for sludge drying reduction.

The low-temperature sludge drying equipment developed by BOE environmental Protection can directly dry sewage or sludge with a moisture content of less than 83% to dry sludge with a moisture content of 10%-30%. The reduction can be as high as 90%, and the effective sterilization can be as high as 90%.

Low energy consumption, no pollution, widely used in municipal sludge and industrial sludge (printing and dyeing, papermaking, electroplating, chemical industry, leather, pharmacy, etc.) for drying reduction.

Dry sludge with 10%-30% moisture content can be gasified later , Mixed burning, composting, or building materials and other harmless resource disposal.

Low temperature drying principle The low-temperature sludge drying equipment independently developed by BOE Environmental Protection uses the principle of low-temperature heat pump dehumidification and uses convection hot air drying to reduce the amount of wet sludge on the mesh belt.

The whole set is the same as a fully enclosed type. Design, dry hot air without heat loss. Dehumidification heat pump principle The refrigeration system is used to cool and dehumidify the humid air from the drying room, and at the same time recover the latent heat of moisture condensation to reheat the dry air.

It is a combination of dehumidification (dehumidification and drying) and heat pump (energy recovery), and is the recycling of energy in the drying process.

Innovative Technology Four-effect technology, twice the industry standard Four-effect condensation dehumidification drying technology is an advanced sludge drying reduction technology.

It has significant advantages such as lower air outlet temperature, better drying capacity and efficiency, and more economical operating costs;adopts "four-effect condensation dehumidification and drying" equipment, and the comprehensive dehumidification performance ratio (SMER) is as high as 4kg.H2O/kw.h or more , The moisture content of dry mud is reduced to 10%-30%, which is more than 50% energy-saving than traditional low-temperature drying, which is twice the industry standard.

A variety of molding technologies, comprehensive energy efficiency leading 40% .

Based on years of successful experience, different types of wet mud, and different moisture content, different molding technologies are used to reduce the drying time of wet mud, and the comprehensive energy efficiency is 40% ahead of the industry.

Wide range of applications 1.It can be widely used in the drying treatment of various types of sludge in municipal administration, printing and dyeing, papermaking, electroplating, chemical industry, leather, etc.;2.The daily dehumidification and water removal capacity of a single device ranges from 200 kg to 50 tons, and all models can meet;3.Electric energy can be used directly, or energy such as steam and waste heat can be used;4.It can be "centralized treatment" or "decentralized treatment" to meet the requirements of sludge disposal policies in different regions;5.

It is not affected by the external environment temperature (low temperature in winter) and humidity (humidity in summer), suitable for use in various regions;Safe and harmless 1. Fully-enclosed low-temperature operation at 40-75ºC, no nitrogen filling operation required;2. During the drying process, the oxy
